Metal Baffle Ceiling · Lobby Installation
Product Description
Standard Metal Baffles are suspended vertical blade-style ceiling elements manufactured from pre-painted galvanized steel or extruded aluminum. Installed in a linear open-ceiling arrangement, they control reverberation and echo in large open-plan spaces while allowing full access to services above. Perfect for retail spaces, airports, lobbies, and transit stations.
Features
- Effective reverberation control in large open volumes
- Custom RAL powder coated finishes & wood-grain options
- Open ceiling design allows full HVAC & service access
- Integrated LED lighting channel options available
- Non-combustible A1 galvanized steel construction
- Snap-on spring clips for tool-free installation
Specifications
| Parameter | Details |
|---|---|
| Material | Pre-painted Galvanized Steel / Aluminum Extrusion |
| Baffle Heights | 50mm, 80mm, 100mm, 150mm, 200mm |
| Baffle Thickness | 0.5mm, 0.6mm, 0.7mm |
| Standard Length | Up to 6000 mm (custom lengths available) |
| Spacing | 50mm to 200mm (project configurable) |
| Finish | Polyester Powder Coat / Woodgrain Sublimation |
Product Photo
Get In Touch
Contact us for Metal Baffle project quotations and shop drawings.
