GI Stud Framing Installation
Product Description
GI Stud 48 × 50mm metal profiles are cold-rolled from high-grade galvanized steel. Engineered as the vertical load-bearing framing component for acoustic drywall partitions and wall lining systems, they provide rigid structural support for acoustic wool insulation and heavy plasterboards.
Features
- Cold-rolled galvanized steel for anti-corrosion
- Pre-punched service slots for cable and pipe routing
- Precise 48mm × 50mm dimension for standard tracks
- High tensile strength and fire-resistant structural core
Specifications
| Parameter | Details |
|---|---|
| Material | Galvanized Iron / Zinc Coated Steel (AZ120 / IS 277) |
| Dimensions | 48 mm × 50 mm |
| Thickness Options | 0.45mm, 0.50mm, 0.55mm, 0.60mm |
| Standard Length | 3.0 meters / 3.6 meters (Custom lengths available) |
Product Photo
Galvanized Steel
Pre-Punched
Fire Resistant
